LC2D32BL
Schneider Electric LC2D32BL TeSys Deca Reversing Contactor 32A AC-3 3P 24V DC low consumption coil. The Schneider Electric TeSys Deca LC2D32BL is a robust pre-assembled reversing contactor, designed for efficient and reliable motor control across diverse industrial applications in Egypt and the Gulf. This 3-pole (3 NO) unit is rated for a 32A AC-3 operational current at <= 440V AC, making it suitable for controlling motors up to 15 kW at 380-400V AC. It features a 24V DC low consumption coil, optimizing energy use and ensuring precise operation, often preferred for modern PLC-controlled systems. The LC2D32BL includes a built-in mechanical interlock and reversing power busbar for simplified installation and enhanced safety. With screw clamp terminals for secure connections and an IP20 front face protection, it's ideal for demanding environments like cement plants, oil and gas facilities, water treatment stations, food and beverage processing, and textile manufacturing. Its reliable performance ensures seamless forward and reverse motor operation, crucial for conveyor systems, pumps, and mixers. For dependable automation solutions, trust Schneider Electric.
Details
- Brand: Schneider Electric
- Part number: LC2D32BL
- Series: TeSys Deca
- Category: Reversing Contactor
Related Schneider Electric parts
- TeSys Deca LC2D32E7 reversing contactor 32A AC-3 3P with 48V AC 50/60Hz coil
- TeSys Deca LC2D32F7 reversing contactor 32A AC-3 3P with 110V AC 50/60Hz coil
- Schneider Electric LC2D32FE7 — TeSys Deca LC2D Reversing Contactor 32A AC-3 3P 115V AC 50/60Hz Coil
- TeSys Deca LC2D32M7 reversing contactor 32 A AC-3 3P 220 V AC 50/60Hz coil
- TeSys Deca LC2D32P7 reversing contactor 32A AC-3 3P with 230V AC coil
- Schneider Electric LC2D32Q7 — TeSys Deca Reversing Contactor 3P 32A AC-3 with 380V AC Coil
- TeSys Deca LC2D32V7 Reversing Contactor 32A AC-3 3P with 400V AC 50/60Hz coil
- TeSys Deca LC2D38B7 Reversing Contactor 3P 38A AC-3 24V AC 50/60Hz Coil
- TeSys Deca LC2D38BD Reversing Contactor, 3P 38A AC-3, 24V DC coil, screw clamp
- TeSys Deca LC2D38E7 reversing contactor 38A AC-3 3P with 48V AC coil
- TeSys Deca LC2D38F7 Reversing Contactor 3P 38A AC-3 110V AC Coil
- TeSys Deca LC2D38P7 Reversing Contactor 38A AC-3 3P with 230V AC 50/60Hz coil
Specifications
- Net weight
- 1.127 Kg
- Motor power kW
- 15 KW at 380...400 V AC 50...60 Hz
- Interlocking type
- Mechanical
- Poles description
- 3P
- Utilisation category
- AC-1, AC-3, AC-3e
- Connections - terminals
- screw clamp terminals
- IP degree of protection
- IP20 front face conforming to IEC 60529
- Manufacturer part number
- LC2D32BL
- Pole contact composition
- 3 NO
- Product or component type
- Reversing contactor
- [Uc] control circuit voltage
- 24 V DC
- Auxiliary contact composition
- 1 NO + 1 NC
- [Ie] rated operational current
- 32 A (at <60 °C) at <= 440 V AC AC-3 for power circuit
- [Ue] rated operational voltage
- Power circuit: <= 690 V AC 25...400 Hz
- Ambient air temperature for operation
- -40…60 °C
