LC1D95BW
Schneider Electric LC1D95BW TeSys Deca contactor 95 A AC-3 3P with 24V DC wide voltage range coil. The Schneider Electric LC1D95BW TeSys Deca contactor is a robust three-pole IEC power contactor designed for efficient motor control and resistive load switching in diverse industrial panels. Featuring a 3-pole (3 NO) configuration, this high-performance device is rated for an operational current of 95 A at <= 440 V AC-3, making it suitable for a broad range of applications. Its wide voltage range 24 V DC control coil ensures reliable operation, while its capacity to handle 45 KW at 380-400 V AC 50 Hz aligns perfectly with common power standards across Egypt and the Gulf. Connections are secured via convenient screw clamp terminals. With integrated 1 NO + 1 NC auxiliary contacts and an IP20 front face protection, the LC1D95BW offers enhanced functionality and safety. This contactor boasts a mechanical durability of 10 Mcycles and an electrical durability of 1.2 Mcycles for AC-3 operations, ensuring a long and reliable service life. It is ideal for critical applications in sectors such as cement production, oil and gas, water treatment, food and beverage processing, textile manufacturing, and building services. To learn more or request a tailored quote for the Schneider Electric LC1D95BW contactor, please contact our sales team today.
Details
- Brand: Schneider Electric
- Part number: LC1D95BW
- Series: TeSys Deca
- Category: Contactor
Related Schneider Electric parts
- TeSys Deca LC1D95E7 contactor 95A AC-3 3P with 48V AC coil
- TeSys Deca LC1D95ED Contactor, 3P 95A AC-3/AC-3e, 48V DC Coil
- TeSys Deca LC1D95F7 contactor 95A AC-3 3P with 110V AC 50/60Hz coil
- TeSys Deca LC1D95FD contactor 95A AC-3 3P with 110V DC coil
- TeSys Deca LC1D95FE7 contactor 95 A AC-3 3P with 115 V AC 50/60 Hz coil
- TeSys Deca LC1D95M7 contactor 95 A AC-3 3P with 220 V AC 50/60Hz coil
- TeSys Deca LC1D95MD contactor, 3P 95A AC-3/AC-3e, 220V DC coil
- TeSys Deca LC1D95N7 contactor 95 A AC-3 3P with 415 V AC 50/60Hz coil
- TeSys Deca LC1D95P7 contactor 95A AC-3 3P with 230V AC coil
- TeSys Deca LC1D95Q7 contactor 95A AC-3 3P with 380V AC 50/60Hz coil
- TeSys Deca LC1D95U7 Contactor, 3P 95A AC-3/AC-3e with 240V AC Coil
- TeSys Deca LC1D95V7 contactor 95A AC-3 3P with 400V AC 50/60Hz coil
Specifications
- Poles
- 3P (3NO)
- Series
- TeSys Deca
- IP Rating
- IP20 front face conforming to IEC 60529
- Terminals
- Screw clamp terminals
- Product Type
- Contactor
- Mounting Support
- Rail, Plate
- Auxiliary Contacts
- 1 NO + 1 NC
- Utilisation Category
- AC-3/AC-3e/AC-4/AC-1
- Mechanical Durability
- 10 Mcycles
- Control Circuit Voltage
- 24 V DC wide voltage range coil
- Rated Breaking Capacity
- 1100 A at 440 V for power circuit conforming to IEC 60947
- Manufacturer part number
- LC1D95BW
- Electrical Durability (AC-3)
- 1.2 Mcycles 95 A AC-3
- Motor Power (AC-3, 380-400V)
- 45 KW at 380...400 V AC 50 Hz (AC-3)
- Rated Operational Current (AC-3)
- 95 A (at <60 °C) at <= 440 V AC-3 for power circuit
- Permissible Ambient Air Temperature
- -40…60 °C
- Rated Operational Voltage (Power Circuit)
- <= 690 V AC 25...400 Hz
