541065
Pilz 541065 PSEN cs3.1p Key 1 switch. Pilz 541065 (PSEN cs3.1p Key 1 switch) is an exact PSENcode machine-safety catalogue item verified against its dedicated Pilz E-Shop detail page. Pilz's model-specific description is: Safety switch for transponder key PSEN cs4.1 Key, 2 safety outputs, M8, 8-pin male connector, coded, accessories: key adapter (532113) and key (541181 or 541182 or 541183 or 541184). The detail-page technical table records Sensor principle: Transponder; Coding level to ISO 14119: gering; Classification to EN 60947-5-3: PDDB; Supply voltage (V): 24; Connection type: M8, 8pol. male; Protection type, housing: IP6K9K; Ambient temperature: -10; Height dimension: 37. This order code is tied to GTIN 4046548099805 and the official technical asset titled 'Operat. Man. PSEN cs3.1p Key'. Similar Pilz variants can differ in contact arrangement, coding, connector, cable, actuator package, sensing distance and enclosure protection, so use the exact product ID and GTIN in RFQs. Availability, price and lead time require a current supplier quotation.
Details
- Brand: Pilz
- Part number: 541065
- Series: PSENcode
- Category: Safety Switch
Related Pilz parts
- PSEN cs4.2p Key 1 switch
- PSEN cs4.1 Key gy3
- PSEN cs4.1 Key gy2
- PSEN cs4.1 Key gy4
- PSEN cs4.1 Key bl
- PSEN cs4.1 Key gy1
- PSEN cs4.1p / PSEN cs4.1 1unit
- PSEN cs4.1n / PSEN cs4.1 1 Unit
- PSEN cs2.1p 1 switch
- PSEN cs3.19n / PSEN cs3.19 1 switch / 3 actuators
- PSEN cs1.1n 1switch
- PSEN cs1.1 1 actuator
Specifications
- GTIN
- 4046548099805
- Volume
- 0 dm3
- Approval
- CE UKCA cULus Listed FCC IC EAC (Eurasian) TÜV
- UNSPSC 25
- 39122205
- unit type
- Sensor
- Net weight
- 35
- Cable lines
- Li9Y11Y 8 x 0,14 mm2
- ETIM Version
- ETIM-9.0
- Gross weight
- 50
- ECLASS version
- ECLASS-13
- Product family
- PSENcode
- Connection type
- M8, 8pol. male
- Depth dimension
- 18
- Humidity rating
- 93 % r. F. bei 40 °C
- Pilz product ID
- 541065
- Width dimension
- 26
- Height dimension
- 37
- Number of inputs
- 2
- Sensor principle
- Transponder
- Supply voltage (V)
- 24
- Transponder coding
- codiert
- Ambient temperature
- -10
- DC voltage at input
- 24 V DC
- EMC to standard ...
- EN 60947-5-3
- Operating frequency
- 122 kHz - 128 kHz
- ETIM Reference Group
- EG000026
- Overvoltage category
- III
- Power consumption DC
- 1
- Official product page
- https://www.pilz.com/en-INT/eshop/Sensor-technology/Safety-switches/PSENcode-non-contact-coded-safety-switches/PSENcode-key/PSEN-cs3-1p-Key-1-switch/p/541065
- Type of tariff number
- TARIC
- ETIM Reference Feature
- EC002592
- Harmonized System Code
- 85365019
- Number of OSSD outputs
- 2
- Number of sig. outputs
- 1
- Acc. shock to standard1
- 30g
- ECLASS Reference Feature
- 27274601
- Protection type, housing
- IP6K9K
- Coding level to ISO 14119
- gering
- Official catalogue branch
- PSENcode-compact
- Potential isolation S/C O
- nein
- Type of supply voltage U1
- DC
- Vibration to standard ...
- EN 60947-5-2
- Perm. operating height ASL
- 4000 m
- Housing material upper part
- PBT
- Quantity per packaging unit
- 1
- Sensor can be flush-mounted
- Ja, Montagehinweis beachten
- Ambient temperature standard
- EN 60068-2-14
- Bend radius (when laying) K1
- 5 x Ø
- Max. ambient temp. at 2000 m
- +55 °C
- Storage temperature standard
- EN 60068-2-1/-2
- Use of customs tariff number
- Ausfuhr Einfuhr
- Climatic suitability standard
- EN 60068-2-78
- WEEE classification (08/2018)
- 5 devices (feed size < 50cm)
- Classification to EN 60947-5-3
- PDDB
- Pollution degree clear.&creep.
- 3
- S/C output short circuit proof
- ja
- Suitable for series connection
- ja
- Utilisation cat. to EN 60947-1
- DC-12
