LC1G400KUEN
Schneider Electric LC1G400KUEN Contactor, high power, TeSys Giga, standard version, 3 pole/NO, AC-3 <=440V 400A, 100-250VAC/DC coil. TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 400A 250kW@440V. It provides a 100-250V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 290mm x 140mm x 209mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data.
Details
- Brand: Schneider Electric
- Part number: LC1G400KUEN
- Series: TeSys Giga
- Category: Contactor
Related Schneider Electric parts
- Schneider Electric LC1G185EHEA — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 185A, advanced version, 48…130V wide band AC/DC coil
- Schneider Electric LC1G185EHEN — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 185A, standard version, 48…130V wide band AC/DC coil
- Schneider Electric LC1G400LSEA — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 400A, advanced version, 200…500V wide band AC/DC coil
- Schneider Electric LC1G1154BEEA — High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 250A, advanced version, 24…48V wide band AC/DC coil
- Schneider Electric LC1G1154EHEA — High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 250A, advanced version, 48…130V wide band AC/DC coil
- Schneider Electric LC1G1154EHEN — High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 250A, standard version, 48…130V wide band AC/DC coil
- Schneider Electric LC1G1154KUEN — High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 250A, standard version, 100…250V wide band AC/DC coil
- Schneider Electric LC1G1154LSEA — High power contactor, TeSys Giga, 4 pole (4NO), AC-1 <=440V 250A, advanced version, 200…500V wide band AC/DC coil
- Schneider Electric LC1G115BEEA — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 115A, advanced version, 24…48V wide band AC/DC coil
- Schneider Electric LC1G115EHEA — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 115A, advanced version, 48…130V wide band AC/DC coil
- Schneider Electric LC1G115EHEN — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 115A, standard version, 48…130V wide band AC/DC coil
- Schneider Electric LC1G115KUEN — High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 115A, standard version, 100…250V wide band AC/DC coil
Request a quote for LC1G400KUEN
Specifications
- Depth
- 226 mm (8.90 in)
- Poles
- 3
- Width
- 140 mm (5.51 in)
- Height
- 225 mm (8.86 in)
- Product Weight
- 7.5 kg (16.53 lb(US))
- Mechanical durability
- 8 Mcycles
- Control circuit voltage
- 100-250 V AC/DC
- Rated breaking capacity
- 3480 A 440 V
- Manufacturer part number
- LC1G400KUEN
- Rated insulation voltage
- 1000 V
- Motor power (AC-3e, 400V)
- 200 kW
- Rated current (AC-3, <=400V)
- 400 A
- Auxiliary contact composition
- 1 NO + 1 NC
- Rated operational voltage (AC)
- <= 1000 V 50/60 Hz
- Rated operational voltage (DC)
- <= 460 V
- Rated impulse withstand voltage
- 8 kV
- Rated short-time withstand current (10s)
- 3.6 kA
