SH202L-C50
ABB SH202L-C50 Miniature Circuit Breaker. The official ABB product page identifies a 2-pole, 50 A, C-curve device with 4.5 kA AC short-circuit capacity at 400 V. This on-request listing makes no stock claim; confirm the recorded ratings and installation conditions before ordering.
Details
- Brand: ABB
- Part number: SH202L-C50
- Series: SH200
- Category: Miniature Circuit Breaker
Related ABB parts
- ABB S203-C1 S200 Miniature Circuit Breaker
- ABB S203-C3 S200 Miniature Circuit Breaker
- ABB S204-C1 S200 Miniature Circuit Breaker
- ABB S204-C2 S200 Miniature Circuit Breaker
- ABB S204-C3 S200 Miniature Circuit Breaker
- ABB S204-C4 S200 Miniature Circuit Breaker
- ABB S204-C6 S200 Miniature Circuit Breaker
- ABB S204-C10 S200 Miniature Circuit Breaker
- ABB S204-C16 S200 Miniature Circuit Breaker
- ABB S204-C25 S200 Miniature Circuit Breaker
- ABB S204-C32 S200 Miniature Circuit Breaker
- ABB S204-C40 S200 Miniature Circuit Breaker
Request a quote for SH202L-C50
Specifications
- EAN
- 4016779944786
- Mounting
- DIN rail TH35-15 or TH35-7.5 acc. to IEC 60715; any position
- Standards
- IEC/EN 60898-1
- Rated current
- 50 A
- Terminal type
- Screw terminals; cage terminal
- ABB material ID
- 2CDS242001R0504
- Number of poles
- 2P
- Rated frequency
- 50 / 60 Hz
- Tightening torque
- 2 N·m
- Product net weight
- 0.22 kg
- Catalog description
- Miniature Circuit Breaker - SH200L - 2P - 50 A - C - (AC) 4.5 kA
- Degree of protection
- IP20; IP40 with enclosure cover
- Electrical endurance
- 10000 AC cycles
- Mechanical endurance
- 20000 cycles
- Product net dimensions
- 35 mm W x 88 mm H x 69 mm D
- Ambient air temperature
- Operation -25 ... +55 °C; storage -40 ... +70 °C
- Manufacturer order code
- 2CDS242001R0504
- Tripping characteristic
- C
- Manufacturer part number
- SH202L-C50
- Rated insulation voltage
- 440 V acc. to IEC/EN 60664-1
- Number of protected poles
- 2
- Rated operational voltage
- 400 V AC acc. to IEC 60898-1
- Rated short-circuit capacity
- 4.5 kA at 400 V AC
- Rated impulse withstand voltage
- 4 kV
